UV-CIPP AT THE INTERNATIONAL AIRPORT OF ROME FIUMICINO

Pubblicato il da

Client: Blueco Srl – Italy

Year: 2010

What I did: I made the detailed design and project management of the rehabilitation, by UV-CIPP, of air-conditioning pipes DN350, laid under runways, at the international airport of Fiumicino Leonardo da Vinci (Rome, Italy).

UV-CIPP AT THE INTERNATIONAL AIRPORT OF ROME FIUMICINO
Longitudinal section of the pipe to be rehabilitated - the host pipe present a 90deg curve and a vertical section.
Preparing the access to the host pipe.
Video inspection of the host pipe.
Preparation of the UV-CIPP liner.
Insertion of the liner into the host pipe.
The capstan winch while pulling the liner into the host pipe.
The UV light core used to polymerize the foto-polymerizing resin.
Inserting the UV light core into the liner.
Inflating the liner before starting the UV polymerization of the resin.
The diagram of the final air pressure test.
The final result: the liner perfectly fits the host pipe.
